Gauze Cutting Rolling Machine TD-B4

main feature :

This new folding machines are developed based on the American folding machines and improves the quality of gauze product. It has special tuck in device which solved the problem of rough selvedge. Because by air suction attached gauze rotation, it avoids the American folding machine with sticky cloth to produce secondary pollution, and the foreign substance of gauze on scavenging effect to a certain extent, improve health.

New gauze folding machine’s structure is simplified, reduce the failure rate, can control gauze piece rate according to the gauze fabrics by frequency conversion , make the machine in best efficiency, easy maintenance and operation.

1

Product details

1、Touch screen control,easy operation and speed adjustable;

2、equipped with digital to ensure the precision of the folding gauze size;

3、No cloth automatically stop;

4、automatic warning device, operation more secure;

5、automatic sprinkler system for the gauze humidifying;

6、Automatic counting function to control the product quantity;

7、The American style of folding;

8、Compared with the traditional machine, production speed is faster;

9、Folding effect more perfect.


Under the fully automatic packaging machine through the membrane stretched forming in accordance with the requirements, then according to the packing in forming the membrane cavity, a driving chain will have to fill in packing cavity automatic moving sealing location, to vacuum and vacuum packaging, then the upper die and lower die bounding, by crosscutting, slitting and packaging to break up, finally packing the finished product delivery to the next working procedure, waste materials from the collector.

This machine is mainly used for packaging of disposable medical products, such as syringes, needles, infusion, blood transfusion bag, gauze piece, surgical towels, bandages, etc., can also be used in food, textile, medicine, toys, tooth brush, etc.

The machine can also be used for paper-plastic composite packaging, can also be used for plastic plastic composite packaging.Plastic film can be soft membrane (PA, PE, etc.).

Packaging form according to the need to customize the other series of auxiliary machines, such as vacuum packing, nitrogen inflator, PVC, PET, PS and so on forming box packaging.

Main technical parameters

Parameters

Model(D4 is standard model)

BN30D4

BN30D4-1

BN40D4

BN40D4-1

BN47D4

BN47D4-1

BN52D4

BN52D4-1

Max. Packing width(mm)

300

300

400

400

470

470

520

520

Vacuum packing maximum width(mm)

296

296

396

396

466

466

516

516

Maximum length of packing(mm)

400

400

400

400

400

400

400

400

Customize max.packing length(mm)

600

——

600

——

450

——

450

——

Min package width

(mm)

19

80

19

80

19

80

19

80

Max. Forming Depth (mm)

80

80

80

80

80

80

80

80

Max.Oper. Frequency (m/min)

15

10

15

10

14

10

13

10

Power Supply

Ac three phase four wire system,380VAC+-10%,50HZ

Instantaneous maximum power(Kw)

13

13

15

15

16

16

18

18

Machine length(cm)

730

780

730

780

730

780

730

780

Machine width(cm)

97

97

107

107

114

114

120

120

Machine height(cm)

195

195

195

195

195

195

195

195

Net weight(Kg)

1.8

1.8

1.9

1.9

1.9

1.9

2

2

Parameters

Model

BN30D4

BN30D4-1

BN40D4

BN40D4-1

BN47D4

BN47D4-1

BN52D4

BN52D4-1

Steam source pressure(continuous working Mpa

>0.5

>0.5

>0.5

>0.5

>0.5

>0.5

>0.5

>0.5

cooling water

Clean water,<25℃

cooling water flow(1/hour)

>60

>60

>80

>80

>80

>80

>100

>100

work environment

dry、clean、10~45℃

The underlying material specifications

Inner dia. 3 inch(¢76mm)paper core,outside dia. <400mm,thickness 0.05~0.7m

The underlying material width(±1mm)

321

321

421

421

491

491

541

541

The top material specifications

Inner dia.3 inch (¢76mm) paper core,outside dia. <400mm,thickness 0.05~0.7m

The top material width(±1mm)

307

307

407

407

477

477

527

527

The top material width(vacuum package,±1mm)

298

298

398

398

468

468

518

518

Equipment Performance

Soft film forming

Forming piercing

+

+

+

+

+

+

+

+

PVC、PET plate forming

-

-

-

-

heating seal

vacuum package

+

+

+

+

+

+

+

+

nitrogen-filled packing

+

+

+

+

+

+

+

+

Accurate to version(Tension control of paper)

Soft membrane crosscutting

Plate crosscutting

-

-

-

-

rip cutting

waste edge winding
