Large Package Winding Machine TD-MLD

Rewinding machine

Used in the production of various kinds of cone yarn, for warping machine, knitting machine, tatting machine and hosiery machine.

Vertical yarn path design, no inflection point, yarn friction is small, less hairiness, equipped with LED light.
Double points tension control system with micro motors, uniform yarn tension.
Using high quality alloy drums with optimized groove shape, good anti-patterning, good wear resistance.

Large Package Winding Machine TD-MLD

main feature :

The large package winding machine TD-MLD which designed for winding cotton yarn, chemical fiber, and filament, low stretch yarn tolarge package of 8 or 10 inch.This machine can be set the length of winding,When yarn breaks it will stop automatically ;whenyarn is fully filled it will also stop;also it has the function of slow start,heat-setting and oiling.This machine assembles with XKH 8or10 inch Ni-P alloy grooved drums with great groove shapewhich have the advantages of good wear resistance and static elimination.

Product details
Main technical parameters
Product evaluation

Inquire Now

Product details

It’s designed for winding cotton yarn, chemical fiber, and filament, low stretch yarn to large package of 8 or 10 inch.

Vertical winder path with no inflection point, little friction and less hairiness. It is appropriate for high speed winding.

Double points tension control system with micro motors, uniform yarn tension. The forming of cheese is good and it can waxing automatically.

Ni-P alloy groove drum with optimized groove shape, which have the advantages of good anti-overlapping characteristics, light weight, good wear resistance, and static elimination.

Single winding motor control for each spindle, electronic fixed-length, single spindle automatic stop while yarn breaking or fully filled.

Main technical parameters

Item	Technical Parameters
Mechanical speed	Up to 800m/min(depending on yarn quality and count)
Package bobbin	0°，3°30’
Package diameter	Up to φ 290 mm
Package weight	Up to10kg
Yarn / count	Cotton. flax, wool,silk, chemical fiber /Ne 6…180
Power consumption	Installed power: 100W/spindle for 8 inch machine, 180W/spindle for 10 inch machine.
Tensioner	Each spindle has a yarn tensioner and a waxing unit
Auto stop while yarn break	With electronic yarn sensor, the spindle will stop when yarn break
Automatic length fixing	Automatic length fixing,max:999999m
Slow start	For smooth start and better winding quality, supporting individual slow start for each spindle
Electronic yarn clearer	Optional
Air splicer	Optional
Travelling blower	Optional, power consumption1.1KW
External dimensions	(8 inch with 4 spindles )1500mm×408mm×1510mm, (10 inch with 4 spindles) 1700×408mm×1510mm
Weight of whole machine	8 inches with 4 spindles: 105kg 10 inches with 4 spindles: 115kg
Power supply	Single phased 220V ，50/60HZ
