TD-1390 Opening Recycling Line

main feature :

This machine is mainly to process all kinds of waste cotton, clips, leftover, waste yarn, thread, flock and flax etc.

This machine is TD630 opening machine combined with mode1390 cotton recycling machine, that make the bestresult.

2
4
3
12

Product details

Airflow recovery instead of bamboo and rubber belt, clean,safe and anti-fireFrequency conversion instead of chain and sprocket drive,High efficiency, energy saving and environmentalprotection.

Main technical parameters

Opening machine Overal dimensions

(installed safety caseLxWxH)

7500mm×2860mm×1380mm

Recycling machine Overal dimensions

(installed safety case LxWxH)

8500mm×2600mm×1200mm

Weight

1500kg

Output

280-400kg/h, depending on different material

Capacity of removing impurities

6%-10%

Cylinder diameter

780-780-300-300-300-300-300-300mm

Cylinder rotation speed

960-1100-1890-1890-1890-1890-1890-1890rpm/min

Power (kw)

45-37-11-7.5-7.5-7.5-7.5-7.5kw

Wire of cylinder

Card clothing/pin/Utype
